DCam D0401 is a functional Mobile Digital Video Recorder specially designed for vehicle video surveillance and remote monitoring. It has a high-speed processor and embedded operating system, combining with the most advanced H.264 video compression / decompression technology as well as GPS positioning technology. It supports not only video recording in 720P, WD1,HD1 and CIF formats, but also vehicle travel information recording and local playback & analysis. It is powerful with flexible installation, easy maintenance and high reliability.

Our cameras are ideally installed in trucks, buses, company delivery vehicles and company vehicles as the benefits to fleet managers are convincing.

4 Camera Capable
Our Commercial Video Recording System allows up to 4 channels of high-quality video and audio to be recorded simultaneously to flashdrive on DVR, letting you know what really happened.

Complete Fleet Safety Solution
Providing a video record of all activity in and around your vehicles on the road, on scene, or at a service location, our Commercial Video Recording System uses an unrivaled combination of side, rear vision and observational video to be the number one choice for a complete fleet safety solution.

360° Coverage
Know what happens in and around your vehicles with full 360° coverage using our rugged, reliable cameras.

GPS Route History
Review route efficiency and safety with available synchronized GPS mapping and tracking embedded within the video recorded by our High-Definition System with an optional GPS Antenna.

Secure Video Storage
Using secure on-site storage rather than vulnerable cloud based servers, our Commercial Video Recording System gives YOU control of YOUR video.

Secure Locking Cage Design
Physical access to the our Commercial Video Recording System is controlled with an included lockable steel cage designed to prevent unauthorized access to the DVR and cable connectors, ensuring video integrity and security.


  • Supports 4 channels WD1+1 channels 720P
  • Supports dual SD cards for main recording
  • Supports GPS for location tracking
  • Supports 360 degree anti-vibration
  • Supports USB2.0 high speed backup
  • Supports data recovery technology




Function Overview Preview, Recording, Playback, Locating
OS Linux 3.0.8
Control Mode Easy Check, CP4, Mouse
Video Input 4 channels WD1+1 channel 720P
Video Output 1 channel
Total Resource (4×25)FPS WD1 @ PAL / (4×30)FPS WD1 @ NTSC +30FPS 720P
Video System Electrical level: 1Vpp Impedance : 75Ω NTSC/PAL Optional
Audio Input 5channels (1 channel IPC audio input)
Audio Output 1channel
Display Split 1/4/9
OSD GPS information, alarm, vehicle No., speed, date/time
Operation Interface Semi-transparent GUI
Video/Audio Compression Video: H.264
Audio: ADPCM
Image Resolution Analog:
PAL: WD1(928X576), WHD1(928X288), WCIF(464X288), D1(704X576), HD1(704×288), CIF(352×288);
NTSC: WD1(928X480), WHD1(928X240), WCIF(464X240), D1(704×480), HD1(704×240), CIF(352×240);
Image Quality 1-8 levels adjustable (1 is the best)
Recording Mode Boot up/Manual/Schedule/Alarm
Pre-recording 0-60minutes
Post-recording 0-30 minutes
Mirror Recording Support
Playback Channel 1 channel by local playback
Search Mode Date/time, channel, event
Network Ethernet 6-pin DJ(100M x 1, PON power supply)
GPS Location tracking, speed detection and time sync
Storage SD card x 2
Interface USB USB2.0 x 1
Interface RS232/RS485 RS232 × 1
Interface Sensor 8 inputs, 2 outputs
Interface Mic I mic interface
Interface Panel CP4 Optional
Power Input DC8-36V,Ignition signal
Power Output 5V@500mA
Power Consumption 29W
Dimension (L × W × H) 167.3mm x 146.3 mm x 54.1mm
Weight 0.83Kg
Operating Temperature -40℃- +70℃(With heater) or -10℃- +70℃
Operating Relative Humidity 8%-90%(No Condense)
